4 megapixel 1/2.9" CMOS sensor
Compression formats: Smart H.265+, Smart H.264+, H.265, H.264, MJPEG
Digital resolution: 4MP (2688x1520), 3.6MP (2560x1440), 3MP (2304x1296), 1080P (1920x1080), 1.3MP (1280x960), 720P (1280x720), D1 (704x576), VGA (640x480), CIF (352x288)
Stream 1: 4MP (1~20 fps), 3.6MP (1~25/30 fps)
Stream 2: D1 (1~25/30 fps)
Day/night mode with removable mechanical filter
Smart IR: 4 leds,60 meters range
0.006 lux F1.5 (color), 0.0006 lux F1.5 (B/W), 0 lux IR On
2.7~13.5 mm motorized optics
Angle of view: 104°~29°(H), 54°~16°(V), 125°~34°(D)
Imaging modes: BLC, HLC, WDR 120dB, 3D-NR, Mirror.
White balance with 6 modes
Automatic and manual gain control
Supports 4-zone videosensor, 4 regions of interest (ROI) and 4-zone privacy masking
Perimeter protection with cross-line detection and intrusion detection (both modes support human/vehicle classification)
SMD Plus
Built-in microphone
MicroSD card slot up to 256GB (not included)
Network interface: RJ45 (10/100 Base-T)
Network protocols: IPv4, IPv6, HTTP, TCP, UDP, ARP, RTP, RTP, RTSP, RTCP, RTMP, SMTP, FTP, SFTP, DHCP, DNS, DDNS, NTP, Multicast, ICMP, IGMP, P2P
ONVIF (Profile S/T), CGI, SDK and API support
Up to 6 users
Remote viewing via IE, Chrome and Firefox browsers
SmartPSS Lite, DSS, DMSS management software
Compatible with IOS and Android mobile devices
Power supply: 12V DC / PoE (802.3af)
Power consumption: 8.7W (12V) / 10.1W (PoE)
Storage temperature from -40°C ~ +60°C
Operating temperature from -30°C ~ +60°C
Relative humidity: =95%.
IP67 protection rating
Metal housing
Dimensions: 90.7 (W) x 90.7 (H) x 238.5 mm (W x H) x 238.5 mm (1.5 x 2.8 in.)
Net weight: 730 g
Gross weight: 990 g
3AXIS: 0°~360°(PAN), 0°~90°(TILT), 0°~360°(Rotation)
